Approx. Dimensions
Width | Length | Height | Capacity |
20ft / 6.1m | 40ft / 12.2m | 8ft / 2.4m | 80-133guest |
Available Color
Available Sidewall
20' X 40' High Peak Tent / Premiere I Tent, one piece tent top, Complete
The Premiere I Series High Peak Pole Tent is designed to provide the tent with elegant curves and impressive peaks similar to our other high peak tents, while also giving the tent added stability through repeated installations and enduring use.
The high peak pole tent can be used to all kinds of event arrangement, especially popular for outdoor parties and weddings.
Available size:
Width: 15’ 20’ 30’ 40’
Length:15’-unlimited
Width | 20 ft. / 6.1m |
Length | 40 ft. / 12.2m |
Area | 800 ft² / 74.4m² |
Eave Height | 8' / 2.4m |
Overall Height | 15'10" / 4.8m |
Pitch | 7' / 2.1m |
Complete Weight | 795 Lbs. / 361 Kg. |
Series / Brand | Premiere I |
Class | Pole |
Center Pole | Yes |
Style / Shape | High Peak |
Expandable | No |
Custom Printing Available | Yes |
Fabric Material | PVC Coated Polyester |
Fabric Material Weight | 16 oz. / yd2 / 540 gsm |
Fabric Translucency | Blockout |
Water Repellency | Waterproof |
Flame Resistant | NFPA-701/CPAI-84/ASTM-D6413/CANULC-S109/DIN4102-B1 |
UV Resistant | Yes |
Mold and Mildew Resistant | Yes |
Frame / Pole Material | Aluminum 6061/T6 |
Longest Component | 8'10" / 2.7m |
Persons required for setup | 2 |
Occupancy | 80 Sit Down Dinner - 133 Cathedral Seating |
